Stage KING Series

Shinning Stage

High Matt Black Customized Design

KING design comes from a new era. New era will embark on the peak of stage. It adopts the corner protect also the brake lock and not falling side lock design, which is a milestone in the industry.

Model No. KING-I2.6 KING-I2.98 KING-I3.91 KING-I4.81
Pixel pitch 2.604mm 2.98mm 3.91mm 4.81mm
Pixel Density 147475 pixel/㎡ 112896 pixel/㎡ 65410 pixel/㎡ 43222 pixel/㎡
Brightness 1200 cd/㎡ 1000 cd/㎡ 1500 cd/㎡ 1300 cd/㎡
Scan 1/32 scan 1/28 scan 1/16 scan 1/13 scan
Panel Dimension (W*H*D) 500x500x85mm/19.7”x19.7”x3.4”
Panel Resolution 192×192 pixels 168×168 pixels  128×128 pixels 104×104 pixels
Panel Weight 7.2KG
Cabinet Material Die casting aluminum
Max power Consumption 800w/㎡
Average power Consumption 270w/㎡
Viewing Angle

H: 120° V:120°

Refresh Rate 3840Hz
Gray Scale 16bits
IP Rating IP43
Operating Temperature -20℃~ +60 ℃
Lifetime 100,000hrs ( about 11 years)
Storage Temperature -30℃~ +70 ℃

Module Corner

Corner protection design is avoiding any hits for modules’corner, 100% protect LEDs.

Not Falling Off  Lock and Seamless Side Lock

The side locks are used to tighten up the cabinets while installing, to reduce the gaps between cabinets. It is good to present the seamless screen.

Easy Take out Back Cover

Directly take out back cover is easy to change within 5 sec.

KING  Cabinet Details

Not Falling off Side Lock

Seamless Side Lock

Brake lock helps the  technician to finish installation in 1 person, save 50% assemble and disassemble time.

KING has 2 kinds of cabinet design, straight cabinet and curve cabinet.

Hanging Installation and Stacking Installation

Connection diagram with control system

Hanging installation



Packing & Delivery

Strong flight case with 8 panels in 1 flight case package

FAQ

Q1. What’s fast delivery time? The production can be controlled as fast as you need from 7 days to 25 days.

Q2. Can I just wait for the items at my door and no need to do others? Yes, items can be delivery to your specific address and you just wait for receiving the items at your door and nothing to do.

Q3. The display will come to me in parts?and i have to install each part together? Yes, but it’s quite easy. We will send you the instruction and also we can remote to help you to adjust the software, everything.

Q4. What’s the function of video processor? It can transfer the video source to make the screen performance more clear. Sometimes there has HD camera, so that the performance can show themselves on the screen as well. Video processor can control stage lights together.

Q5. How can I install the led display?

There are two options, one is hanging the display, the other is standing the display. Hanging bars and back stacking will be provided.
