Product Description
Outdoor WIN X LED Wall with High Brightness
WIN X Series
A versatile design
Specification
Type
P4.704
P6.67
P8
P10
Pitch(mm)
4.704mm
6.67mm
8mm
10mm
Pixel Density (dots/sqm)
45156
22500
15625
10000
LED Type
SMD1921
SMD2727
SMD2727
SMD2727
Cabinet size(mm)
960*960*95mm
Cabinet material
Die casting aluminum
Cabinet weight(kg)
37KG
Scan Mode
1/9
1/6
1/5
1/2
Brightness (cd/sqm)
5000
5500
4500
5000
High contrast
4000:1
Gray Scale(Bit)
16bits
IP Rating
IP65
Viewing angle
H:120 degrees, V:120 degrees
Power consumption Max/Ave (w)
800/270

New Invention vs Old Fashion

1.material: Die casting Aluminum, 31KG.
2.Dimension: 960x960x95mm.
3.Cost saving during installation based on our 13 years of experience: 5-10USD per hour and per person.1.material: steel, 45KG.
2.Dimension: 960*960*135mm.
Simple cable connection
1.Power and signal 2 in 1 interface.
2.Each cable takes control of one module and has no influence on the next one.
3.Much less cables than the old fashion, the led display can work more stably.
Simple structure design
1.No high power fans.
2.No back cover.
3.Saving installation frame fees. Usually 70-100USD per square meter.

Fast lock, Fasten the connection between the cabinets and make it higher flatness(less than 0.1mm with CNC processing).

Power plug
Signal plug, only 3 sec at the most to connect one cable.

320x320mm aluminum module

Die casting aluminum kit, better heat dissipation salt and corrosion resistance.

Four corner precise module quick installation knob, prevent displacement during transportation less gaps between modules.

Traditional screws design merely for rear maintenance. 100-180seconds needed to loose every single screw.

How to handle front maintenance
Notes: before any operation, power needs to be cut off.

Installation way
