LED |
NationStar SMD1010 | NationStar SMD1010 | NationStar SMD1010 | NationStar SMD1515 |
NationStar SMD2121 |
|
Pixel Pitch |
1.25mm | 1.5625mm | 1.953mm | 2.604mm |
3.91mm |
|
LED Module Size (mm) |
W500 x H62.5 x D14mm |
||||
|
LED Module resolution (pixels) |
400 x 50 pixels | 320 x 40 pixels | 256 x 32 pixels | 192 x 24 pixels |
128 x 16 pixels |
|
Signal processing capabilities |
14-16 bit | ||||
| Grayscale grade |
4096-65536 |
||||
|
Refresh Rate（Hz） |
≥3840 Hz |
||||
|
Scanning Method |
1/50 | 1/40 | 1/32 | 1/24 |
1/16 |
|
Brightness |
>800cd/m² | >900cd/m² |
>1000cd/m² |
||
|
Best viewing distance (meter) |
≥ 1.2m | ≥ 1.5m | ≥ 1.9m | ≥ 2.6m |
≥ 3.9m |
|
Weight |
16kg/㎡ | ||||
|
Viewing angle（°） |
140° |
||||
| Input voltage（V） |
DC 24V |
||||
|
Maximum power consumption |
512w/sqm |
||||
|
Average power consumption |
170w/sqm |
||||
|
Temperature |
-20 ℃/+50℃ (working)/‐40 ℃/ +60℃ (storage) |
||||
|
Protection level |
IP 65 / IP 41 |
||||
|
Humidity |
10%~90% (working) 10%~90% (storage) |
||||
|
Lifetime（hours） |
100000 | ≥100,000 |
≥100,000 |
||
|
Maintenance method |
Rear |
||||
| NovaStar Control System |
A5S PLUS |
||||
